Swing Gates
Premium Swing Gates for Secure & Stylish Property Access
HINGED SWING GATES
Why Are Hinged Swing Gates Are So Popular in the UK?
Hinged swing gates remain the most popular choice of driveway gates in the UK. These gates are attached to gate posts using hinges and typically open to ninety degrees or slightly more. They offer a traditional appearance, reliable performance, and are suitable for most residential driveways.
If you are planning to install a pair of swinging electric driveway gates, there are several important factors you should consider to ensure safe, long-term operation.
Choosing the Right Gate Size
Most cars, including 4×4s, measure less than 2100mm wide including mirrors. To allow all cars and light commercial vehicles to pass comfortably, design your entrance width at around 3600mm, assuming the approach is reasonably straight.
Your electric gate operator must control the swing gates safely and hold them securely in both the open and closed positions in all weather conditions. The operator attaches to the post next to the hinge to perform this function.
Think about which end of a manual gate you would grab to hold it closed or open it. Now try doing the same from the opposite end of the gate – this demonstrates the constant force the motor and brackets must handle.
Bearing the above in mind you will appreciate that keeping your gate size, weight and wind resistance to a minimum will have a large effect on the stresses put upon your electric gate system.
Gate Design & Wind Resistance
An open pattern metal gate or timber gate will allow a majority of the wind to blow through it with little resistance. A close boarded gate will have a sail affect and require much more force to move it in windy conditions.
It is important to consider this when gates and operators are to be fitted in exposed positions. An experienced gate fitter will give advice on the electric gate operators best suited to your choice of gates. A more powerful operator will often be specified for wind affected gates.
Selecting the Right Type of Gate
There is a wide range of swing gate styles and materials available to suit different properties and budgets.
Options include:
Handmade ornate iron gates
Modern aluminium gates
Hardwood timber gates crafted by skilled joiners
Each material offers different benefits in terms of maintenance, durability, aesthetics, and weight. A professional installer can help you select the best option based on your driveway layout and automation requirements.
Electric Gate Operators for Swing Gates
You can automate electric swing gates using either post-mounted or underground gate operators. When installing new gates, hinge them to match the specific mounting dimensions of your chosen operator. If you install gates first and then hire a contractor to automate them, you may need to remove and re-hang the gates. That’s why involving a specialist gate installer from the very beginning makes sense. Our registered installers guide you through every step – from initial survey to final handover – and help you avoid the common mistakes that non-specialist contractors often make.
